Fdc 2s 22s 3a 7.4v 8.4v 18650 Lithium Lipo Cell Battery Charger Board Li ion Battery Charging Pcb Bms Protection Module Hx 2s 01

The FDC 2S-22S 3A Battery Charger Board is a versatile and high-efficiency PCB designed to manage the charging of 7.4V and 8.4V lithium-ion (Li-ion) and lithium polymer (LiPo) 18650 battery cells. This advanced charging module integrates a Battery Management System (BMS) to provide comprehensive protection, ensuring the safety and longevity of your battery packs. Ideal for both DIY electronics enthusiasts and professional battery management systems, this board delivers reliable performance and robust safety features.

Key Features:

• Wide Voltage Compatibility: Supports charging for 7.4V (2S) and 8.4V (2S) lithium-ion and lithium polymer battery packs. This makes it suitable for various battery configurations and applications.

• High Charging Current: Capable of handling up to 3A charging current, allowing for efficient and rapid charging of your battery cells. This high-current capability helps reduce charging time and improves overall convenience.

• Integrated BMS Protection: Equipped with an advanced Battery Management System (BMS) to safeguard your batteries against overcharging, over-discharging, and short circuits. These protection features enhance the safety and reliability of the charging process.

• Efficient Charging: Designed to provide stable and efficient charging with minimal energy loss. The PCB ensures consistent performance and optimizes the charging cycle for better battery health.

• Compact and Durable Design: The board features a compact form factor that allows for easy integration into various electronic projects and battery systems. Its durable construction ensures long-lasting performance and reliability.

• Clear Connectors and Labels: Comes with clearly labeled connectors and pins for straightforward installation and setup. The user-friendly design facilitates quick connections and minimizes the risk of incorrect wiring.

Applications:

• DIY Electronics Projects: Perfect for hobbyists and engineers building custom battery-powered devices or upgrading existing systems with a reliable charging solution.

• Battery Management Systems: Integrate this charger board into battery management systems to efficiently manage and charge lithium-ion and lithium polymer battery packs.

• Power Storage Solutions: Use the board in energy storage systems to provide safe and efficient charging for lithium-based batteries, ensuring reliable performance and extended battery life.

• Portable Devices: Ideal for charging lithium-ion and lithium polymer batteries used in portable electronics and gadgets, offering quick and reliable power replenishment.

  Technical Specifications:

  • Charging Current: Up to 3A
  • Supported Battery Types: Lithium-Ion (Li-ion), Lithium Polymer (LiPo)
  • Supported Battery Voltages: 7.4V (2S), 8.4V (2S)
  • Protection Features:
    • Overcharge Protection: Prevents charging beyond the maximum voltage limit.
    • Over-Discharge Protection: Stops discharging when the battery voltage drops too low.
    • Short Circuit Protection: Guards against damage caused by short circuits.
  • Dimensions: [ 50mm x 30mm x 5mm]
  • Weight: [  15g]
  • Mounting Type: Surface mount
